Products Description
The continuous rolling flat bag making machine is a fully automated, high-efficiency packaging equipment specially developed for the mass production of roll-type flat bags. Adopting integrated mechanical and electrical control design, the machine realizes one-stop continuous operation from film unwinding, tension adjustment, automatic deviation correction, heat sealing, perforation, fixed-length cutting to finished product rolling and winding. It is compatible with mainstream packaging materials such as HDPE and LDPE plastic films, and can stably produce various specifications of flat roll bags including supermarket shopping bags, food packaging flat bags, household garbage roll bags and industrial packaging flat bags.
1. Double‑lane simultaneous production for higher yield
2. Built‑in core rewinding unit for paper‑core finished rolls
3. Accurate perforation system for easy‑tear bag‑on‑roll
4. Servo + PLC control for stable running and simple operation
5. Compatible with LDPE, HDPE and partial biodegradable plastic films
Company Profile
Our company, Ruian Mingfeng Machinery Co., Ltd., is located in Ruian, Zhejiang Province, China. Founded in 2000, our facility covers a land area of 5,000 square meters with 1,000 square meters of standardized workshops and a workforce capacity of up to 100 employees. We are one of the large‑scale machinery manufacturers based in Ruian.
We specialize in manufacturing a wide range of plastic machinery, including plastic film blowing machines, plastic bag‑making machines, plastic recycling machines, slitting & rewinding machines, and printing machines.
Our address
NO. 2568 Dongshan Economic Industry, Ruian, Zhejiang Province, Wenzhou, Zhejiang, China 325200
Phone Number
86-151-67807851
mingfengmachinery@163.com
| Model | MFW-500 |
| Applicable Material | LDPE, HDPE, LLDPE, Biodegradable film (PBAT+PLA) |
| Bag Width | 100 ~ 300 mm |
| Bag Length | 200-1000 mm |
| Film Thickness | 0.008 ~ 0.04 mm |
| Max Film Line Speed | 80 ~ 100 m/min |
| Running Speed | 100 ~ 300 pcs/min per channel |
| Optional Device | Automatic web guide, pneumatic roller, automatic roll change, T-shirt hole punching unit |
| Rewinding Mode | Core rewinding / Coreless rewinding optional |
| Total Installed Power | 12 ~ 16 KW |
| Power Supply | 380V, 3-phase, 50Hz |
| Control System | PLC + Touch Screen + Servo feeding system |
| Overall Dimension(L×W×H) | 3600 × 1300 × 1700 mm |
| Machine Weight | 3300 KG |
